Main Specifications
| Specifications | ||
| Sensors | ||
| Frequency band | 2 kHz to 65 kHz | |
| Detection range1 | 0.5 to > 70 meters (1.6 to > 230 feet) |
|
| Field of view (FOV) | 63°± 5° | |
| Nominal frame rate | 25 FPS | |
| Built-in digital camera (visible light) | ||
| Field of view (FOV) | 63°±5° | |
| Focus | Fixed lens | |
| Zoom | 3 x digital zoom | |
| Resolution | 5 MP | |
| Display | ||
| Size | 7″ LCD with backlight, sunlight readable | |
| Resolution | 1280 x 800 (1,024,000 pixels) | |
| Touchscreen | Capacitive | |
| Acoustic image | SoundMapTM image | |
| Image storage | ||
| Storage capacity | 32 GB (> 8,000 pictures / > 1,600 videos) |
|
| Image format | Blended visual and SoundMapTM .JPG or .PNG | |
| Video format | Blended visual and SoundMapTM .MP4 | |
| Video length | Up to 5 minutes | |
| Digital export | USB-C for data transfer | |
| Acoustic measurements | ||
| Measurement range (typical) | 15.4 to 115.2 dB SPL (± 1 dB SPL 2 kHz) 5.6 to 102.5 dB SPL (± 2 dB SPL 19 kHz) 28.4 to 131.1 dB SPL (± 1 dB SPL 35 kHz) 41.8 to 133.1 dB SPL (± 3 dB SPL 52 kHz) |
|
| Classification and quantification | ||
| LeakQTM | Leak size scale, Leak rate, and Leak cost estimation | |
| PDQ ModeTM | – | |
| MecQTM | – | |
| Auto max/min dB gain | Auto or manual, user selectable | |
| Frequency band selection | User selectable through user-made presets or manual entry | |
| Battery | ||
| Battery | Rechargeable and field replaceable Li-ion battery | |
| Battery life | 6 hours | |
| Battery charging time | ~3,5 hours | |
| Battery charging system | Internal (USB-C) | |
| Software | ||
| Ease of use | Intuitive user interface | |
| Acoustics: Show dB scale | On/Off | |
| Acoustics: Min/Max dB | Manual/Auto | |
| Acoustics: Profiles | Preset capture profiles | |
| Acoustics: High frequency | – | |
| Acoustics: Multiple sources | Show single or multiple sources | |
| Palette: Colors | 3: Grayscale, Ironbow, and Blue-Red | |
| Palette: Overly transparency | Yes: 1-100% | |
| Grayscale mode | Yes | |
| Centerpoint markers | On/Off | |
| Trend graphs | Frequency and dB scale | |
| Spotmarkers | dB level reading at center point of image | |
| Leak values | Leak costs, Leak volume, LeakQTM scale (1-10)2 | |
| Master admin menu | Yes | |
| Annotation | Asset name; Asset ID; Asset type; Leak type; Gas type; Pressure | |
| Photo notes | Up to 4 photos notes for reference | |
| Asset inspection status | ‘As left’, ‘As found’, ‘Undetermined’ | |
| Asset ID | Text input and automatic QR code based asset ID identification | |
| Actions annotation | Action requirements, Action priority level, Action notes | |
| Other | Operating conditions, Weather notes | |
| General specifications | ||
| Tripod holder / connector | Yes: 1/4″-20 | |
| USB | 2 x USB-C | |
| Wireless | Wifi | |
| Operating Temperature | -10 to 40 °C (14 to 104 °F) | |
| Storage Temperature | -20 to 70 °C (-4 to 158 °F) without batteries installed | |
| Relative humidity | 10 to 95 % non-condensing | |
| Size (H x W x L) | 186 mm x 322 mm x 68 mm (7.3 inches x 12.7 inches x 2.7 inches) | |
| Weight (battery included) | 2 kg (4.4 pounds) | |
| Ingress Protection (IP) | IP40 | |
| Warranty | 2 year | |
| Fluke Premium Care | Premium Care Standard3 | |
| Self-diagnostic notification | Array-health test to identify when microphone array needs attention | |
| Supported languages | Dutch, English, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Simplified Chinese, Spanish, Swedish, Traditional Chinese | |
| RoHS compliant | Yes | |
| Safety | ||
| General safety | IEC 61010-1 | |
| Electromagnetic Compatibility (EMC) International | IEC 61326-1: Portable Electromagnetic Environment IEC 61326-2-2 CISPR 11: Group 1, Class A | |
| Korea (KCC) | Class A Equipment (Industrial Broadcasting and Communication) | |
| USA (FCC) | 47 CFR 15 sub part B. This product is considered an exempt device per clause 15.103 | |
| ¹ Depending on ambient conditions ² 1-10 Scale (independent of Leak Type) ³ Subject to regional availability (www.fluke.com/premiumcare) |
||
