DESCRIPTION
| ASIC TECHNOLOGY | More Functions & Features At Affordable Prices |
| LARGE 6000 COUNTS LCD DISPLAY | 5/Sec Fast Nominal Updata Rate |
| HIGH ACCURACY | 0.2% Basic DCV Accuracy |
| ANALOG BAR-GRAPH | Fast Update Rate 40/Sec |
| LOGIC LEVEL Hz (mV FUNCTION) | Measures Hi Frequency Logic Signals |
| LINE LEVEL Hz (V FUNCTION) | Measures Noisy High Voltage ACV Frequencies |
| EF-DETECTION | Both Non-Contact (NCV) & Single-Probe Voltage Detection For Identifying Live Lines |
| DATA HOLD | Freezes The Displaying Reading For Later View |
| AUTO-POWER-OFF | To Extend Battery Life |
| ERGONOMIC STREAMLINE DESIGN | Fits Comfortably In One’s Hand |
| TRANSIENT PROTECTION | Up To 6kV 1.2/50μs Lightning Surge; Superb Protection For Serious Users |
| EMC | Meets EN61326-1:2013 |
| LVD SAFETY | Meets EN61010-1/-2-030/-2-033 CAT II 1kV, CAT III 600V & CAT IV 300V |
| RUGGED & DURABLE | High-Impact Fire-Retarded Enclosure For Reinforced Safety & Durability |
| PC INTERFACE CAPABILITY | Optional Purchase RS232C+USB Cables With DATA Recording PC Software For Win7/8/10 |
| PROTECTIVE HOLSTER | With Holders For Probe Storage And “Third Hand” Feature Replaceble & Washable |
| BEEP-JACK AUDIBLE WARNING | Beeps Against Improper Current Terminals Plug In. Decreases Risks Of Damage |
| FAST AUDIBLE CONTINUITY | For Quick Open-Short Tests On Switches, Fuses, And Wires |
| DIODE TEST | For Checking Diodes & Rectifiers |
| HIGH IMPEDANCE VOLTAGE | 1000VAC/DC Measuring Capabilities; High Input Impedance For Load Sensitive Circuits |
| FUNCTION SELECTION | Toggle Conveniently Between Primary & Secondary Functions |
| AUTO & MANUAL-RANGING | Auto-Ranging With Manual-Ranging Override |
| HIGH SPEED AUTO-RANGING | Shortens The Time To Test And Increases The Ease Of Use |
