Specifications
Key features
Infrared resolution
640 x 480 (307,200 pixels)
SuperResolution
No
IFOV with standard lens (spatial resolution)
0.93 mRad, D:S 1065:1
Field of view
34 °H x 24 °V
Minimum focus distance
15 cm (approx. 6 in)
MultiSharp Focus
No
LaserSharp Auto Focus
Yes, for consistently in-focus images. Every. Single. Time.
Laser distance meter
Yes, calculates distance to the target for precisely focused images and displays distance on screen
Advanced manual focus
Yes
Wireless connectivity
Yes, to PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available)
Fluke Connect app compatible
Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing
Fluke Connect Assets
Through the desktop, assign images to assets, easily compare measurement types in one location and create reports.
Fluke Connect instant cloud upload
Yes*, connect your camera to your building’s WiFi network, and images taken automatically upload to the Fluke Connect system for viewing on your smartphone or PC
Fluke Connect instant server upload
Yes**
IR-Fusion technology
Yes, adds the context of the visible details to your infrared image
Ruggedized touchscreen display
3.5 inch (landscape), 640 x 480 LCD
Ergonomic design
Pistol-grip design for one-handed use
Thermal sensitivity (NETD)**
≤0.075 °C at 30 °C target temp (75 mK)
Level and span
Smooth auto and manual scaling
Touchscreen adjustable level/span
Yes. Span and level can be easily and quickly set by simply touching the screen
Fast auto toggle between manual and auto modes
Yes
Fast auto-rescale in manual mode
Yes
Minimum span (in manual mode)
2.0 °C (3.6 °F)
Minimum span (in auto mode)
3.0 °C (5.4 °F)
Built-in digital camera (visible light)
5MP
Frame rate
60 Hz or 9 Hz versions
Laser pointer
Yes
LED light (torch)
Yes
Digital zoom
No
Data storage and image capture
Extensive memory options
Removable 4 GB micro SD memory card, 4 GB internal flash memory, save to USB flash drive capability, upload for permanent storage
Image capture, review, save mechanism
One-handed image capture, review, and save capability
Image file formats
bmp, jpeg, is2
Memory review
Thumbnail and full screen review
Software
Full analysis and reporting software with access to the Fluke Connect system
Analyze and store radiometric data on a PC
Yes
Export file formats with Fluke Connect software
Bitmap (.bmp), GIF, JPEG, PNG, TIFF
Voice annotation
60 seconds maximum recording time per image; reviewable playback on camera, optional Bluetooth headset available but not required
IR-PhotoNotes
Yes – 2 images
Text annotations
Yes. Including standard shortcuts as well as user programmable options
Video recording and formats
No
Remote control operations
Remote display through Fluke Connect
Auto capture (temperature and interval)
No
Battery
Batteries (field-replaceable, rechargeable)
Two lithium ion smart battery packs with five-segment LED display to show charge level
Battery life
2-3 hours per battery (actual life varies depending on settings and usage)
Battery charging time
2.5 hours to full charge
Battery charging system
Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter
AC operation
AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
Power saving
User selectable sleep and power off modes
Temperature measurement
Temperature measurement range (not calibrated below -10 °C)
-20 °C to +650 °C
(-4 °F to +1,202 °F)
Accuracy
±2 °C or 2 % (at 25 °C nominal, whichever is greater)
On-screen emissivity correction
Yes (both value and table)
On-screen reflected background temperature compensation
Yes
On-screen transmission correction
Yes
Line temperature graph
No
Color palettes
Standard palettes
9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Ultra Contrast palettes
9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Smart lenses
Macro-25 micron lens: 25 MAC2
Yes
2 x telephoto lens: TELE 2
Yes
4 x telephoto lens: TELE4
Yes
Wide angle lens: WIDE 2
Yes
General specifications
Color alarms (temperature alarms)
High temperature, low temperature, and isotherms (within range)
Infrared spectral band
7.5 μm to 14 μm (long wave)
Operating temperature
-10 °C to +50 °C (+14 °F to +122 °F)
Storage temperature
-20 °C to +50 °C (-4 °F to +122 °F)
Relative humidity
10 % to 95 % non-condensing
Center-point temperature measurement
Yes
Spot temperature
Hot and cold spot markers
User-definable spot markers
No
User defined measurement boxes
1 expandable-contractible measurement box with MIN-MAX-AVG temp display
Hard Case
Rugged, hard carrying case; soft transport bag
Safety
IEC 61010-1: Overvoltage category II, Pollution Degree 2
Electromagnetic compatibility
IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A
Australian RCM
IEC 61326-1
US FCC
CFR 47, Part 15 Subpart B
Vibration
0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
Shock
25 g, IEC 68-2-29
Drop
Engineered to withstand 2 meter (6.5 feet) drop with standard lens
Size (H x W x L)
27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5 in)
Weight (battery included)
1.04 kg (2.3 lb)
Enclosure rating
IEC 60529: IP54 (protected against dust, limited ingress; protection against water spray from all directions)
Warranty
Two-years (standard), extended warranties are available
Recommended calibration cycle
Two-years (assumes normal operation and normal aging)
Supported languages
Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
RoHS compliant
Yes
