Specifications
Specifications
Jaw opening
12.9 mm (0.5 in)
Max wire size
1/0 THHN Cable
Current range AC rms
0 to 100.0 A
Accuracy AC current (50/60 Hz)
3% ± 3 counts
AC response
Averaging
Voltage range AC/DC
0 to 600 V
Voltage accuracy
AC
1.5% ± 2 counts
DC
1% ± 1 count
Resistance range
0 to 1000 Ω
Continuity beeper threshold
On at < 25 Ω, off at > 400 Ω
Volts indicator LED threshold
Guaranteed on by 30 V AC
Environmental Specifications
Operating temperature
-10°C to 50°C
Storage temperature
-30°C to 60°C
Humidity (without condensation)
0% to 95% (5°C to 30°C);
0% to 75% (30°C to 40°C);
0% to 45% (40°C to 50°C)
Dust/water resistance
Yes
Operating altitude
2000 meters max
Temperature coefficient
0.1 x (specified accuracy)/°C (< 18°C or > 28°C)
Safety Specifications
Measurement Category
IEC 61010-2-032, IEC61010-2-033: CAT III 600 V, 100 A ac
Agency approvals
CSA, TUV
Maximum voltage
600 V between any terminal and earth ground
Mechanical and General Specifications
Size
30.5 x 51 x 203 mm
Weight
300 g
Warranty
Two-years
Battery life
200 hour zinc chloride, 400 hour alkaline
Battery type
2 x AA
Low battery indicator
Yes
Current sensor opening
12.9 mm
