Specifications
Specifications
Media
Mineral oil or deionized water. (Oil is default media liquid. Pump with water as media to be ordered specifically)
Reservoir Capacity
420ml (25.6 in^3)
Generated Pressure Range
0 psi to 15,000psi (1,000bar).
Material
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N
Connection
Hand-tight connectors for both test gauge and reference gauge.
Test Gauge Connection: 1/4NPT female, 1/4BSP female, or M20X1.5 female
Dimensions
Height: 7.8″ (200 mm)
Base: 18.1″ (460 mm) x 14.3″ (365 mm)
Weight
28.7 lb (13 kg).
Piston Volume
Fine adjust piston: 1.5 ml
