Specifications
MODEL CONTRAST
Model
FR2000A+
FR2000+
FR2000B+
FR2000C+
Resistance range
0.01Ω-200Ω
0.01Ω-500Ω
0.01Ω-1200Ω
0.01Ω-1200Ω
Class type
Utility-type
Basic type
Explosion proof type
Multifunction type
Resistance resolution
0.001Ω
0.001Ω
0.001Ω
0.001Ω
Current range
NO
NO
NO
0.00mA-20A
Current resolution
NO
NO
NO
0.01mA
TECHNICAL PARAMETERS
Function
Ground resistance test, Loop resistance test, *leakage current test
Power Supply
4 section AA alkaline dry battery
Measurement Method
Mutual induction
Clamp Diameter
55mm×32mm
*Ω+A Synchronized display
Ω+A same screen display
Display Mode
4-digit LCD display, black screen design
LCD Dimension
46mm×29mm
Meter Dimension
W/T/H: 85mm×58mm×285mm
Sampling Speed
About 2 times/second
Data Review
“MR” symbol indication when reviewing data
Overflow Display
Exceed measurement range overflow function: “OL” symbol display
Interference Test
Automatic identify interference signal, “NOISE” symbol indication when the interference current is large
Alarm Function
Alarm when the measured value exceeds the alarm setting value
Battery Voltage
Real-time display of battery power, reminding timely change when battery voltage is low
Automatic shut-down
“APO” instruction, automatic shutdown after 5 minutes boot
Power Consumption
50mA Max
Weight
Instrument: 1180g (with battery)
Production Compliance
IEC61010-1 (CAT III 300V, CAT IV 150V, Pollution Grade 2); IEC61010-031; IEC61557-1
IP
IP45
