Specifications
Range
0.0mA-1200A ( 50/60Hz Auto )
Resolution
0.1mA
Clamp Diameter
φ50mm
Accuracy
±2%rdg±5dgt
Sampling Speed
2 times/second
Function
High-low voltage current measurement
Power Supply
DC6V Alkaline Dry Battery (1.5V AAA × 4)
Test Method
Clamp CT
Meter Dimension
Host Dimension : W/T/H 87*37*262mm
LCD Dimension
48mm×31mm
Total Weight
2.5Kg (including insulation rod and battery)
Overflow Display
Exceed measurement range overflow function : “OL” symbol display
Data Storage
99 groups
Data Storage Full
Data full function : “FULL” symbol display
Battery Voltage
When the battery voltage is below 5.2V, the symbol of battery voltage is low will show
Insulated Rod
5 sections insulation rods ( total 5 meters )
Insulation strength
AC 60kV/rms
Circuit Test
Insulation sheath wire test below 60kV line voltage, bare wire test under 35kV (with insulation rod operation)
Work Temperature
-10°C ~ 40°C
Storage Temperature
-10°C ~ 60°C
Humidity
0°C ~ 31°C ≤ 75% , 31°C ~ 40°C ≤ 50%
Suitable for safety regulations
IEC1010-1, IEC1010-2-032, Pollution Level 2, CAT III (600V) IEC61326 (EMC Standard)
IP
IP45
