Specifications
Function
Voltage detection, cable tracking
Reference Conditions
23℃±5℃, Below 75%rh
Voltage Ranges
380V; 6 kV; 10 kV; 27.5 kV; 35 kV; 110 kV; 220 kV; 500 kV
Insulation rod
4 sections 3.5 meters (Optional)
Power Supply
DC 9V (6F22 1PC)
Instrument size
115mm(L) × 115mm(W) × 169mm(H)
Protection class
IP65
Indicating function
Sound and light Indicating when the detection voltage exceeds the setting voltage
Weight
390g (With battery)
Operating temperature and humidity
-10℃ ~ +50℃ < 85%RH
Storage temperature and humidity
-15℃ ~ +55℃ < 90%RH
Safety regulations
EN 61326-1 CISPR 11
EN 61000-4-2 EN 61000-4-3
EN 61000-4-8
