Specifications
Type of material
Optional Cu, Al, Fe, Au, Ag materials
Resistance range
10.0uΩ-1000.0kΩ
Resolution
0.1 uΩ
Accuracy
±0.2%FS
Test method
Four wire method test
Test current
20A, 10A, 5A, 1A, 0.1A, 10mA, 1mA
Temperature detection
The temperature probe
Temperature conversion
Yes, in the temperature conversion, it can be converted to 75℃ measurement results
Alert setting function
Yes
Overload protection
Yes
Self discharge
Have, LCD display reminder
Power supply
Built-in: 12.6V 12Ah rechargeable lithium iron phosphate battery
Charging function
Yes, 14.6V/3A
Backlight
Yes, sliding adjustable, suitable for dim place use
Display mode
5-inch touch (854×480) Full-color LCD display
Touch screen operation
Yes
Instrument size
Length 277.2mm × width 227.5mm × high 153mm
Test cables length
5 meters, red, black each
Cloud services
Android APP, the upper machine
USB cable
USB one pcs communication cable
Data transmission
USB / Bluetooth
Data access
There is a data access function
Overflow display
Overload overflow function: The OL symbol display
Power dissipation
Standby: about 230 mA (20% brightness)
Measured at: 27W Max
Weight
Instrument: 2300g (including battery)
Test cables: 850g
Production Compliance
IEC61010-1, CAT III 600V, Pollution Grade 2, JJG724-1991, JJG166-1993
IP
IP45
