Specifications
Function
DC resistance measurement, transformer DC resistance measurement
DC Resistance
DC Resistance: 0.0001mΩ~5000Ω
Accuracy: 0.2%FS±5dgt
Minimum resolution: 0.001mΩ
Output current display
0.01mA~20.000A
Replace the resistance
Can be converted to the measurement temperature of the winding material
Three-phase imbalance rate
Automatically display three-phase winding imbalance rate
Separate position
You can manually set the distribution position manually at the setting interface
Overload protection
Yes
Automatic discharge
Yes
Rated measurement power
1000W
Power supply
AC 220V 10A (50Hz)
Backlight
Adjustable backlight brightness
Measurement method
Four-line test
Magnetic Test
High, low-voltage output current, test low-pressure resistance
Short-circuit test current
0.2A, 0.5A, 2A, 5A, 10A, 20A (set settings)
Short-circuit maximum current
DC 20A±10%
Voltage maximum voltage
DC 27V±10%
Display mode
7-inch touch color screen
Touch screen
Yes
Measuring instruction
Setting progress display, measurement prompt animation display
Meter size
High length and height: 450mm × 350mm × 180mm
Standard test line
Article 8
U disk interface
Used to connect to the U disk special interface
USB interface
Save data to the computer-specific software through the USB cable
Print
Built-in thermistor printer
Printed paper specification
57 × 40mm
Data storage
500 groups
Suitable for security
IEC61010-1, IEC1010-2-31, IEC61557-1.5, IEC60529 (IP54), pollution, etc. 2, CAT III 300V
IP
IP54
