Specifications
Model FR17B FR17C Maximum count 4000 count 6000 count Range switching Automatic Automatic DC voltage 0.00mV ~ 750V± ( 0.5% + 3 ) 0.00mV ~ 1000V± ( 0.5% + 3 ) AC voltage 0.00mV ~ 600V± ( 0.8% + 5 ) 0.00mV ~ 750V± ( 0.8% + 5 ) DC current 0.0uA ~ 10.00A± ( 1.2% + 3 ) 0.0uA ~ 20.00A± ( 1.2% + 3 ) AC current 0.0uA ~ 10.00A± ( 1.5% + 3 ) 0.0uA ~ 20.00A± ( 1.5% + 3 ) Capacitance 0.00nF ~ 40.00mF ± ( 3.0% + 5 ) 0.00nF ~ 100.0mF ± ( 3.0% + 5 ) Resistance 0.0Ω ~ 40.00MΩ ± ( 1.0% + 3 ) 0.0Ω ~ 60.0MΩ ± ( 1.0% + 3 ) Frequency 0.00Hz ~ 10.00MHz ± ( 1.0% + 3 ) 0.00Hz ~ 10.00MHz ± ( 1.0% + 3 ) Duty cycle 0.0% ~ 99.9% ± ( 1.0% + 3 ) 0.0% ~ 99.9% ± ( 1.0% + 3 ) Temperature -20 ~ 1000 degrees Celsius; -4 ~ 1832 degrees Fahrenheit; ±1.0% of reading or ±3℃ AC Voltage/Current
Frequency Response40Hz~500Hz True valid value Have Max/Min Have Data retention Have Diode Have Continuity test Have NCV voltage detection Have Zero fire line judgment Have Flashlight Have Test lead port indication Have LCD screen display Have Backlight Have Low voltage indication Have 1 meter drop test Have Safety level CAT III 1000V/ CAT IV 600V IP IP45
