Specifications
Power
Rechargeable lithium battery pack 9.6V, external charger
Display mode
LCD color screen, 64dots×480dots, 5.6 inch, display field 116mm×88mm
Instrument size
L/W/H: 277.2mm×227.5mm×153mm
Number of channels
4 channels voltage, 4 channels current
Line voltage
1.0V～2000V
Phase voltage
1.0V～1000V
Current
008 tip small current clamp: 10mA～10.0A Jaw size: 8mm×15mm (selection)
020 round-mouth current clamp : 0.10A～100A Jaw size: 20mm×20mm (selection)
050 round-mouth current clamp : 1.0A～1000A Jaw size: 50mm×50mm (selection)
Rogowski coil : 10A～6000A
Optional transformer
Instrument port input current 1mA～500mA
Electric power and power quantity parameter
W , VA , var , PF , DPF , cosφ , tanφ
Electric energy parameter
Wh , varh , VAh
Harmonic
Have, 0～50 times
Total harmonic distortion
Have, 0～50 times , each phase
Export mode
Have
Number of transient record groups
150 groups
Voltage flicker
Have
Start current mode
Have, 100 second
Three-phase unbalance
Have
Record
30 days ( Record 20 parameters at the same time, record 1 point every 5 seconds )
Minimum/maximum recorded value
Yes, can measure the maximum and minimum within a period of time
Alarm
40 different types of parameter selection, 12800 group alarm logs
Peak value
Have
Phasor diagram display
Automatic
Screenshot capacity
60
Production Compliance
IEC61010 1000V Cat III / 600V CAT IV, IEC61010-031, IEC61326, Pollution Grade 2
IP
IP45
