Specifications
Specifications
Function
DC volts
Range / resolution
50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V
Basic accuracy
0.025%
AC volts
Range / resolution
50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V
Basic accuracy
0.4% (True-RMS)
DC current
Range / resolution
500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A
Basic accuracy
0.05%
AC current
Range / resolution
500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A
Basic accuracy
0.6% (True-RMS)
Temperature (excluding probe)
Range / resolution
-200.0°C to 1350.0°C (-328.0°F to 2462.0°F)
Basic accuracy
1.0%
Resistance
Range / resolution
500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ, 5.0000 MΩ, 50.00 MΩ, 500.0 MΩ
Basic accuracy
0.05%
Capacitance
Range / resolution
1.000 n, 10.00 nF, 100.0 nF, 1.000 μF, 10.00 μF, 100.0 μF, 1000 μF, 10.00 mF, 100 mF
Basic accuracy
1.0%
Frequency
Range / resolution
99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz
Basic accuracy
0.005%
Connectivity
Optional infrared connector via Fluke ir3000 FC
General Specifications
Maximum voltage between any terminal and earth ground
1000 V
Battery type
6 AA alkaline batteries, IECLR6
Battery life
100 hours minimum, 200 hours in logging mode
Temperature
Operating
-20°C to 55°C
Storage
-40°C to 60°C
Relative humidity
0 to 90% (0 t 37°C), 0 to 65% (37°C to 45°C), 0 to 45% (45°C to 55°C)
Electromagnetic compatibility
EMC EN61326–1
Vibration
Random vibration per MIL-PRF-28800F Class 2
Shock
1 meter drop per IEC/EN 61010–1 3rd Edition
Size (H x W x L)
22.2 x 10.2 x 6 cm (8.75 x 4.03 x 2.38 in)
Weight
870.9 g (28 oz)
Multiple on screen displays
Yes
True-RMS AC bandwidth
100 kHz
dBV/dBm
Yes
DC mV resolution
1 μV
Megohm range
Up to 500 MΩ
Conductance
50.00 nS
Continuity beeper
Yes
Battery/fuse access
Yes/Yes
Elapse time clock
Yes
Time of day clock
Yes
Min-max-avg
Yes
Peak
250 μs
Duty cycle
0.01% to 99.99%
Pulse width
0.025 ms, 0.25 ms, 2.5 ms, 1250.0 ms
Hold
Yes
Isolated optical interface
Yes
Auto/touch hold
Yes
Reading memory
Yes
Log to PC
Yes
Interval/event logging
Yes
Logging memory
Up to 10,000 readings
Wireless connectivity (optional)
Yes
