Specifications
Function / Model FR133F FR133G Accuracy AC Voltage (V) 400mV / 4V / 40V / 400V / 600V 400mV / 4V / 40V / 400V / 1000V ±(0.5%+3) DC Voltage (V) 4V / 40V / 400V / 600V 4V / 40V / 400V / 1000V ±(0.8%+3) ACV / Bandwidth (Hz) 1kHz 1kHz ±(0.5%+5) DC Current (A) 400uA / 40mA / 400mA 400uA / 40mA / 400mA ±(1%+5) 10A 10A ±(2%+5) AC Current (A) 400uA / 40mA / 400mA 400uA / 40mA / 400mA ±(1%+5) 10A 10A ±(2%+5) Capacitance(F) 40nF ~ 400n ~ 400uF 40nF ~ 400n ~ 400uF ±(4%+5) 4000uF / 40000uF 4000uF / 40000uF ±(8%+5) Frequency(Hz) 10Hz ~ 40kHz 10Hz ~ 100kHz ±(0.5%+5) Battery Test 1.5V / 9V – ±(2.5%+5) HFE – 0 ~ 1000 – NCV/Live Phase Sequence NCV / LIVE NCV / Live Phase Sequence – AC/DC600A(CurrentCamp) – 0.1A ~ 600.0A (1A = 1mV AC / DC) ±(3%+5) Temperature (°C) – (-40°C ~ 1000°C) ±(1.5%+4) Temperature (°F) – (-58°F ~ 1832°F) ±(2%+4) FEATURES Display Counts 4000 Auto Range Auto True RMS ● Connuity / Diode ● NCV (Red LED Flashing) ● AC Live ● Auto power off ● Backlight / Torch ● Power AAA1.5V×2 Category Ratings CAT III 300V CAT II 600V
