Specifications
Function / Model
FR203E
FR204E
Accuracy
DC Current (A)
40A / 400A
60A / 600A
±(2%+5)
AC Current (A)
40A / 400A
60A / 600A
±(2%+5)
DC Voltage (V)
600V
600V
±(0.5%+3)
AC Voltage (V)
600V
600V
±(0.8%+3)
LowZ AC Voltage (V)
–
600V
±(1.5%+5)
ACV / Bandwidth (Hz)
400Hz
1kHz
–
ACA / Bandwidth (Hz)
60Hz
60Hz
–
Frequency (ACV Hz)
40kHz
60kHz
±(0.5%+5)
Resistance(Ω)
400Ω~400kΩ
600Ω~600kΩ
±(1%+5)
4MΩ~40MΩ
6MΩ~60MΩ
±(2%+5)
Capacitance (F)
40nF / 400uF
60nF / 600uF
±(4%+5)
40000uF
60mF
±(8%+5)
Temperature (℃)
–
(-50℃~1000℃)
±(1.5%+4)
Temperature( ℉)
–
(-58℉~ 1832℉)
±(2%+5)
FEATURES
Display Counts
4000
6000
ACV LowZ
–
●
Jaw Opening
Φ28mm
Auto Range
●
True RMS
●
Connuity / Diode
●
Auto power off
●
Backlight / Torch
●
Battery
AAA1.5V×2
Category Ratings
CAT III 300V CAT II 600V
