Specifications
Function /Model
FR207C
FR207D
Accuracy
AC Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
INRUSH Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
DC Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
DC High Voltage (V)
1000V
1700V
±(0.5%+5)
AC High Voltage (V)
1000V
1000V
±(0.5%+5)
LowZ AC / DC Voltage (V)
100 ~ 1000V
100 ~ 1000V
±(1.5%+5)
AC/V Bandwidth (Hz)
1kHz
1kHz
–
AC/A Bandwidth (Hz)
60Hz
60Hz
–
Frequency (Hz)
10MHz
20MHz
±(0.5%+5)
Resistance (Ω)
600Ω / 6kΩ / 60kΩ / 600kΩ
6MΩ / 60MΩ600Ω / 6kΩ / 60kΩ / 600kΩ
6MΩ / 60MΩ±(1%+5)
±(2%+5)
Capacitance (F)
60nF ~ 600nF ~ 6000nF
60000nF / 60000uF60nF ~ 600nF ~ 6000nF
60000nF / 60000uF±(4%+5)
±(8%+5)
Temperature (℃)
–
1000℃
±(1.5%+4)
Temperature (℉)
–
1832℉
±(2%+5)
FEATURES
Display Counts
6000
Auto Range
●
True RMS
●
ACA PEAK
●
ACV/VFD
●
Connuty / Diode
●
NCV (Red LED Flashing)
●
AC Live
●
Max / Min
●
Zero / Rel
●
