Specifications
Model FR205B FR205D Maximum count 4000 Count 6000 Count Range switching Auto DC voltage 0.1mV~400.0V(±0.8%+5) 0.1mV~600.0V(±0.8%+5) AC voltage 0.001V~400.0V(±0.8%+5) 0.001V~600.0V(±0.8%+5) DC Current 0.001A~400.0A(±2.0%+5) 0.001A~600.0A(±2.0%+5) AC Current 0.00A~400.0A(±2.0%+5) 0.00A~600.0A(±2.0%+5) Capacitance 0.000nF~40.00mF(±3.0%+5) 0.000nF~100.0mF(±3.0%+5) Resistance 0.01Ω~40.00MΩ(±1.0%+3) 0.01Ω~60.00MΩ(±1.0%+3) Frequency 0.01Hz~10.00MHz(1.0%+3) 1.0Hz~? (1.0%+3) Duty cycle 0.1%～99.9%(±1.0%+3) Temperature -20～1000 Degree Celsius；-4～1832 degree Fahrenheit Degree;±1.0% of reading or ±3℃ AC Voltage/Current
Frequency Response40Hz～500Hz True RMS Have Have Max/Min Have Data retention Have Diode Have On-off test Have Zero/Fire-line judgment Have 1 Meter Drop Test Have Backlight Have LCD Size 3.8mm×30mm Electric Supply Two 1.5V batteries (2xAAA) Safety Grade CAT III 600V/ CAT IV 600V Product Weight Approx. 332g(without battery) Meter Size 218mm×76mm×38mm IP IP45
